FI-8N NCF High End Performance AC Connector (C7 IEC)

Nano Crystal² Formula (NCF)
Incorporated into selected Furutech products, NCF features a special crystalline material that has two ‘active’ properties. First, it generates negative ions that eliminate static. Second, it converts thermal energy into far infrared. Furutech combines this remarkable material with nano-sized ceramic particles and carbon powder for their additional ‘piezoelectric effect’ damping properties. The resulting Nano Crystal² Formula is the ultimate electrical and mechanical damping material. Created by Furutech, it is found exclusively in Furutech products.

Furutech is known the world over for a huge variety of top-quality OEM parts and delivers consistently superior results by following Pure Transmission principles; examine every link in the power and signal path and ultimately optimize each and every element. Furutech celebrate their 25th anniversary with the introduction of an updated and improved version of their very first power connectors, the FI-8N series. The FI-8N series features a new plating technique which delivers sonic improvements with a more durable finish and newly designed cable clamps for firm grip and resonance control.

– Rhodium-plated α(Alpha) Beryllium Copper Conductor
– Floating Field Damper System* prevents induced magnetic fields
– Nylon /fiberglass with special “NCF” anti-resonance damping material – nano-sized crystalline, piezo ceramic particles and carbon powder main body
– Specified for cable diameters of 6.0mm to 13.0mm
– Wire size of 2.4mm² (13AWG) max. (Solid Core) and 2.0mm² (14AWG) max. (Stranded)
– Connection: Set screw
– Dimensions: 36.8mm X 28.2mm X 71.0mm overall length
– Rating:  7A 125V / 2.5A 250V AC
